Borgward bx5

TECHNICAL DATA*

• BODY / DIMENSIONS
• DRIVE SYSTEM / DRIVING PERFORMANCE
• CHASSIS / BRAKES

• 	Borgward BX5
  Body	Four-door, 5-seater SUV, self-supporting and reinforced lightweight steel body with safety passenger cell, energy-absorbing crash zones front / back, side impact protection
  Length mm	4,490
  Width mm	1,877
  Height mm	1,675
  Wheelbase mm	2,685
  Axle track f/h mm	1,609 / 1,609
  Unladen weight/ payload kg	1,640 / 420
  Seats	5

• 	Borgward BX5
  Engine type / cylinder	Four-cylinder light metal inline motor, high-pressure direct injection with piezo injectors, turbocharger with intercooler, variable valve control, EGR
  Cubic capacity cm3	1,797
  Bore x stroke mm	82 x 85.1
  System power kW/hp at rpm	140 / 190 5,500
  Max. torque Nm at rpm	280 1,750 – 4,500
  Tank capacity l	60
  Drive	Permanent torque-on-demand all-wheel drive with electronically controlled multi-discclutch, ESP, traction control
  Transmission system	Six-stage automatic torque converter transmission
  Maximum speed km/h	190

• 	Borgward BX5
  Front axle	MacPherson axle, transverse control arm, spring struts, coil springs, gas-filled shock absorber, anti-roll bar
  Rear axle	Multi-arm axle, coil springs, gas-filled shock absorber
  Brakes	Disc brakes front and rear, ventilated disc brakes front, ABS, EBD, braking assistant, electric handbrake, auto hold
  Steering	Electromechanical rack-and-pinion steering
  Wheels / tyres	8.5 J x 18 / 235/60 R 18, tyre pressure monitoring system for specific tyres

ACTIVE AND PASSIVE SAFETY

• The body with its highly stable passenger cell and defined deformable barriers at the front and rear is the reliable foundation for superb occupant protection. Crucial body sections are reinforced with high-strength, ultra high-strength or hot-rolled steel. Should, however, the worst come to the worst, several load paths distribute the impact energy in the event of a head-on, side or rear crash and therefore ensure that the deceleration values that are configured exactly to the passive safety equipment are as balanced as possible.

• The passive safety equipment unfolds its maximum protection potential. For the different kinds of crashes, such as head-on, side or rear collisions, alongside the belt systems there are also up to six air bags provided, which are activated as required depending on the severity of the accident and can dramatically mitigate the consequences of an accident on the occupants. These include two-stage hybrid air bags for the driver and front passenger, side air bags for the driver and front passenger and curtain air bags over both rows of seats.

• So that the passive safety equipment remains as inactive as possible, the Borgward BX5 offers several preventive driving dynamics and driver assistance systems that can prevent accidents as part of the “B-Safe” concept. These include, for example, the blind spot alert, road sign assistant, fatigue alert or “pre-filling” the brakes in the event of rapid deceleration.





















• Systems such as the 360° dome camera also make handling the Borgward SUV even more comfortable particularly in confusing situations and help prevent minor damage. Parallel and diagonal parking manoeuvres are no problem at all and drivers can complete tight shunting manoeuvres in a narrow car park or in confusing terrain to the centimetre. And Borgward drivers don’t need to take narrow exits blind as the front and rear camera makes crossing pedestrians, cyclists and cars visible on the central display.
